The Cascade U.H.F. repeater amplifier is a through powered unit, designed to operate in conjunction with any Fringe masthead amplifier. This enables long coaxial cable runs to be used where the T.V. is remote from the aerial. Depending on the model of masthead, channel group, and aerial signal available a distance of 200 metres may be obtained, using standard grade coaxial cable, one masthead, and one Cascade amplifier. A distance of 800 metres may be obtained, by using distribution grade coaxial cable, and three Cascade amplifiers.

The WB22/2 is a wide band U.H.F. amplifier with in-built low loss splitter. This enables two television sets to operate from one masthead amplifier. The power unit must be switched on to operate either T.V. In strong signal reception areas each leg may be split again using Fringe Inductive Splitters; this enables 2, 3 or 4 set reception.

Retail Price - £     Quantity:       205-031   WB 22/2
Retail Price - £     Quantity:       206-011   Cascade



** For UK & Eire; a suitable 4G filter may be required.
